Products Description
The Boxerly BXL-V50 portable veterinary ultrasound scanner can detect early pregnancy, uterine inflammation, ovarian swelling, and fetal count in common livestock such as pigs, cows, sheep, horses, and donkeys.











Tags:Veterinary UltrasoundPortable Veterinary Ultrasound
Text link:https://www.bxlultrasound.com/pdt/7.html
Technical parameter

Portable Veterinay Ultrasound Machine

Portable Veterinary Ultrasound BXL-V50

Portable USG veterinary ultrasound Machine BXL -V10Ⅲ
BXL-V50 Technical Parameters
1. The whole machine is waterproof and dustproof, and the waterproof level is IP56; strong and durable
2. Left and right buttons (convenient for left and right hand operation)
3. Work for more than 7 hours on one charge
4. Display: 8.0-inch high-definition LCD display;
5. Measurement of back fat, eye muscle, automatic back fat thickness measurement, lean meat rate measurement function
6. Probe upgrade, no appendages
7. Professional customized sun visor, adjustable
8. One-key shutdown protection function
9. Position markings: beef cattle, dairy cows, buffaloes, goats, sheep, alpaca, pigs, cats, dogs, etc., no less than 45 kinds of animal position markings are optional;
10. Grayscale: 256;
11. Multiple fast measurement methods;
12.16 Number of channels;
13. Storage: One key storage; and support U disk storage preview, etc.
14. Host rated input: DC14V 3.0A;
15. Adapter output: DC14.0V 3.0A;
16. Network power supply: 100-240V~1.2-0.6A Frequency: 50-60Hz;
17. Patented products, more than three patents
18. Weight: the weight of the whole machine is 1.2KG
19. Image frame rate: 60
20. Image U disk/TF card storage and browsing function;
21. Pseudo-color: a variety of pseudo-color processing;
22. Multiple system preset functions;
23. Host size: about 206 x 120 x 35 (mm, length x width x height);
24. Grid setting quick measurement function;
25.Host memory≥8G
